Minebea Intec - Explosion Proof Scales

For devices to be used safely in potentially explosive environments, their safety levels have to be compatible with local safety requirements. As a reliable partner for industry, Minebea Intec holds international approvals such as IECEx, ATEX, NEC, CEC and NEPSI, as well as a comprehensive range of industrial bench and floor scales for potentially explosive environments. All scales can be used as explosion-proof solutions in EX zones 1 and 21.



Bench and floor scales for hazardous areas

Industrial Scales Signum The bench scale Signum has been specifically developed as a compact solution for a variety of industries. All scales in the range are based on strain-gauge (SG) or electromagnetic force compensation (EMFC) technology. Within everyday weighing applications, they stand out thanks to their short measurement times, flexibility, and safety.

Weighing Platforms IS Digital high-resolution weighing platforms with IP protection rate IP54. Resolution: 1 x 3,000 e or 2 x 3,000 e (verified for legal metrology); 15,000 d or 30,000 d for non-verified versions. Weighing range: 0.62kg up to 300kg

Weighing Platforms Combics Modular system of weighing platforms for sophisticated weighing tasks. Resolution 3,000 e or 2 x 3,000 e, accuracy class III, verified for legal metrology; 15,000 d or 30,000 d for non-verified versions. Weighing range 3kg up to 3,000kg.

Floor Scales IF The flat-bed scale IF has been developed for the maximum possible ground-level use in the smallest possible space. It is a high quality, flexible and mobile weighing station, which can be used anywhere in the production process where reliable measurements and hygienic solutions are required.

Pallet Scales IU The best pallet scale IU comes in 48 basic models, allowing us to offer an individual weighing solution for the widest possible range of industry requirements at any time.



Weighing Terminals for hazardous areas

Weight Controller Maxxis 5 The freely programmable process controller, designed for applications as diverse as Phase, Batching, Filling, IBC, Counting and Truck Weighing. Extensive connectivity options and compatibility with all analogue load cells and digital load cells as well as platform scales and many more weighing solutions.

Combics CAIXS2-Ex Combics provides support in all areas of your process chain, from manual formulations up to PC- controlled production checks. The modular system allows tailor-made configuration of the individual components for each area. Individual complete solutions are available according to your specific applications. For use in explosive areas (certificates: IECEx | ATEX Zone 1 | 2 | 21 | 22 and FM Class I, II, III Div. 1).



Pricing and quotes

For more information about Minebea Intec Scales and Balances, call our sales department at 513-777-1525 or toll free at 800-572-9689 or contact us online by filling out the Alpha Liberty online contact form and an associate will contact you at their earliest convenience.
